12V 50AH LITHIUM ION BATTERY

Product: SB50 SKU: 796762840892 Weight: 15 lbs

Quantity
Price $689.99 +Add to wishlist

Product Details

COMMERCIAL    MARINE        UPS        RV    AUTOMOTIVE

 The Smart Battery 12V 50AH Lithium Ion Battery features an automatic built in battery protection system (BPS) that keeps the battery running at peak performance and protects the cells for thousands of cycles. The SB50 is plug and play for any application that currently uses a lead acid, gel or agm battery.


POWER & ENERGY

THE ELECTRIC ADVANTAGE

Nominal Voltage 12.8V
Charge Voltage 14.4V - 14.6V
Peak Discharge (5 Sec) 500A
Continuous Charge / Discharge Rate 50A
Capacity (amp hours) 50AH
Capacity (watt hours) 600WH


SIZE & WEIGHT
ADVANTAGE

Model SB50
Group Size 12V50A
Weight 15 Lbs
Length 7.7"
Width 6.45"
Height 6.75"


TECHNOLOGY
ADVANTAGE

Usable Capacity (AH) 50AH
Depth of Discharge 100% DOD
Reserve Minutes @ 20A 150 min
Self Discharge <3% per mo
Chemistry Lithium Iron Phosphate (LiFePO4)
Cell Type Cylindrical
Modular Series or Parallel Connection



SAFETY & PROTECTION
ADVANTAGE

Built in Automatic Battery Protection System        Internal
Automatic Low Voltage Disconnect 8V
Automatic Short Circuit Protection Instant
Automatic Over Voltage Protection 15.8V
Automatic Reverse Polarity Protection Instant
Internal Cell Thermal Safety Fuse Yes
Flame Retardant Electrolyte Yes
Length Way Circuit Boards Yes
Automatic Internal Cell Balancing Yes
Automatic Fault Recovery Yes
Explosion Proof Stainless Steel Cells Yes



TEMPERATURE PERFORMANCE
ADVANTAGE

Celsius Fahrenheit  Usable Capacity
60 140 103%
50 122 102%
40 104 100%
30 86 100%
20 68 98%
10 50 92%
0 32 83%
-10 14 80%
-20 -4 70%
-30 -22 60%
-40 -40 10%
-50 -58 0%



FAST SHIPPING
ADVANTAGE

Standard Shipping UPS GROUND
Expedited Air Shipping UPS WORLDWIDE EXPRESS
Shipping Time Ships within 24 hours



LIFETIME WARRANTY
ADVANTAGE

Repair or Replace First 5 Years
Repair or Pro Rate Life Time
Detailed Warranty Information Warranty



This Product Is Perfect For

Motorhomes, Travel Trailers, Fifth Wheels, Boats, Yachts, Sailing, Trolling Motors, Electronics, Solar Backup Power, and Other Deep Cycle Applications.


The Smart Battery 12V 50AH Lithium Ion Battery is the perfect replacement from a AGM, GEL or Lead Acid Battery. The SB50 is designed as a "drop in replacement
" meaning all you have to do is take out your old battery and place the SB50 in the same way.



Or send us a quick message and we will get right back to you





SB50 Data
SB50 Data Specs
