RICH SOLAR 24V 1200W Complete Solar Kit – Sleek Black Finish Off-Grid System with 6x200W Panels, 5.12kWh LiFePO4 Battery & 3000W Inverter for RV, Cabin & Backup
Model #: RS-CK1200 SKU: RS-CK1200
Product Details
Product Description for RICH SOLAR 1200 Watt 24V Complete Solar Kit – Sleek Black Finish with 6x200W Panels, 3000W Inverter & 5.12kWh LiFePO4 Battery
RICH SOLAR 24V 1200W Complete Solar Kit – Sleek Black Finish Off-Grid System with 6x200W Panels, 3000W Inverter & 5.12kWh LiFePO4 Battery for RV, Cabin & Backup
Achieve flexible energy independence with the RICH SOLAR 24V 1200W Complete Solar Kit (Sleek Black Finish), a fully integrated, high-performance system for reliable solar power. This complete package includes six 200W monocrystalline solar panels (1200W total), a 60A MPPT charge controller, a 3000W pure sine wave inverter, two 25.6V 100Ah Alpha 4 LiFePO4 batteries (5.12kWh total), and all necessary accessories — everything needed for whole-home backup, full-time RV living, cabins, or off-grid businesses.
Key Features • High-Power 1200W Solar Array – six 200W monocrystalline panels (sleek black finish, 21.3% efficiency) for maximum output in varying light conditions. • 60A MPPT Charge Controller – optimizes battery charging with overcharge/reverse polarity protection, LCD monitoring, and support for LiFePO4/AGM/Gel/Flooded batteries. • 3000W Pure Sine Wave Inverter – 120V AC output with 6000W surge, 88% efficiency, multiple outlets for appliances, tools, and electronics. • 5.12kWh LiFePO4 Storage – two 25.6V 100Ah Alpha 4 rack-mount batteries with 5000+ cycles, 100A BMS, self-heating, and IP65 rating. • Pre-Wired & Plug-and-Play – includes Z-brackets, 30A inline fuses, Y-branch adapters, solar/battery cables (#10-8 AWG, 10-30ft), and quick disconnects. • Fully Expandable – add more panels, batteries (up to 4p4s), or inverters for growing energy needs. • Smart Monitoring – LCD display on controller and inverter for real-time performance tracking. • All-Weather Performance – -40°F to 185°F operation with weather-resistant components. • Certified & Safe – UL1741 inverter, UL1973/ETL batteries, UL61730 panels, FCC/UN38.3 compliant.
Specifications at a Glance Inverter Power: 3000W continuous / 6000W surge • Voltage: 24VDC input, 120V AC output • Efficiency: 88% Battery Capacity: 5.12kWh (2 × 25.6V 100Ah) • Max Charge/Discharge: 100A/110A per battery • Cycle Life: 5000+ Solar Input: 1200W max (6 × 200W panels) • VMP: 18.4V • VOC: 21.8V • Efficiency: 21.3% Controller: 60A MPPT • Max PV Input: 150V / 1600W (24V) • Operating Temp: -31°F to 113°F Dimensions (approx): Inverter 18.7 × 9.6 × 4.0 in | Batteries 20.9 × 8.1 × 8.5 in each | Panels 58.7 × 26.8 × 1.2 in each Weight: Inverter 12.1 lbs | Batteries 48.5 lbs each | Panels 23.6 lbs each Warranty: 5 years inverter/controller, 10 years batteries, 25 years panels
Ready for off-grid living or reliable backup power? This RICH SOLAR 1200W Kit is in stock and ships fast from lithiumion-batteries.com!
