12V 100AH LITHIUM ION BATTERY

Product: SB100 SKU: 796762840885 Weight: 28 lbs

Quantity
View Quantity Discounts
Price $1,299.99 $1,499.99 +Add to wishlist

Product Details

IN STOCK

COMMERCIAL     MARINE          RV      AUTOMOTIVE


The Smart Battery 12V 100AH Lithium Ion Battery features an automatic built in battery protection system (BPS) that keeps the battery running at peak performance and protects the cells for thousands of cycles. The SB100 is plug and play for any application that currently uses a lead acid, gel or agm battery.



POWER & ENERGY
THE ELECTRIC ADVANTAGE

Nominal Voltage 12.8V
Charge Voltage 14.4V - 14.6V
Peak Discharge (5 Sec) 1000A
Continuous Charge / Discharge Rate 100A
Capacity (amp hours) 100AH
Capacity (watts) 1280W


SIZE & WEIGHT
ADVANTAGE

Model SB100
Group Size 31
Weight 28 Lbs
Length 12.75"
Width 6.5"
Height 8.7"


TECHNOLOGY
ADVANTAGE

Usable Capacity (AH) 108AH
Depth of Discharge 100% DOD
Reserve Minutes @ 20A 300 min
Reserve Minutes @ 50A 120 min
Self Discharge <3% per mo
Chemistry Lithium Iron Phosphate (LiFePO4)
Cell Type Cylindrical
Modular Series or Parallel Connection



SAFETY & PROTECTION
ADVANTAGE

Built in Automatic Battery Protection System        Internal
Automatic Low Voltage Disconnect 8V
Automatic Short Circuit Protection Instant
Automatic Over Voltage Protection 15.8V
Automatic Reverse Polarity Protection Instant
Internal Cell Thermal Safety Fuse Yes
Flame Retardant Electrolyte Yes
Length Way Circuit Boards Yes
Automatic Internal Cell Balancing Yes
Automatic Fault Recovery Yes
Explosion Proof Stainless Steel Cells Yes



TEMPERATURE PERFORMANCE
ADVANTAGE

Celsius Fahrenheit Usable Capacity
60 140 103%
50 122 102%
40 104 100%
30 86 100%
20 68 98%
10 50 92%
0 32 83%
-10 14 80%
-20 -4 70%
-30 -22 60%
-40 -40 10%
-50 -58 0%



FAST SHIPPING
ADVANTAGE

Standard Shipping UPS GROUND
Expedited Air Shipping UPS WORLDWIDE EXPRESS
Shipping Time 24 HOURS



LIFETIME WARRANTY
ADVANTAGE

Repair or Replace First 5 Years
Repair or Pro Rate Life Time
Detailed Warranty Information Warranty



This Product Is Perfect For

Motorhomes, Travel Trailers, Fifth Wheels, Boats, Yachts, Sailing, Trolling Motors, Electronics, Solar Backup Power, and Other Deep Cycle Applications.


The Smart Battery 12V 100AH Lithium Ion Battery is the perfect replacement from a group 31 AGM, GEL or Lead Acid Battery. The SB100 is designed as a "drop in replacement
" meaning all you have to do is take out your old group 31 battery and place the SB100 in the same way.
