Xantrex Freedom SW 3000W 12V Inverter/Charger (815-3012)
Model #: 815-3012 SKU: XANTREX-815-3012
Product Details
Xantrex Freedom SW 3000W 12V Inverter/Charger (815-3012)
Xantrex Freedom SW 3000W 12V Inverter/Charger (Model: 815-3012) – Premium Pure Sine Wave Power Solution for RV, Marine, and Off-Grid Systems
Elevate your mobile and off-grid power systems with the Xantrex Freedom SW 3000W 12V Inverter/Charger (Part No: 815-3012), a high-capacity unit combining a 3000W pure sine wave inverter, 150A multi-stage battery charger, and 30A automatic transfer switch. Designed for RV camping, marine applications, and off-grid solar setups, this inverter/charger delivers clean, stable power for sensitive electronics, heavy appliances, and tools while rapidly recharging 12V batteries from shore or generator power. Advanced features like generator support, customizable charging profiles, and compatibility with the System Control Panel (SCP) ensure precise control and unmatched reliability. Key Features:
- Pure Sine Wave Inverter: Delivers 3000W continuous (6000W surge) for clean, stable power, ideal for laptops, medical devices, and heavy loads.
- Multi-Stage Battery Charger: 150A output with customizable profiles for flooded, AGM, gel, or lithium batteries, featuring temperature compensation for optimal charging.
- Automatic Transfer Switch: 30A relay switches between inverter and AC input in under 20ms for seamless power transitions.
- Generator Support Mode: Automatically manages generator input to supplement charging or power heavy loads.
- Configurable Settings: Adjustable via optional System Control Panel (SCP) for charge rates, battery type, and AC input prioritization.
- Power Sharing: Prevents AC breaker trips by prioritizing load power over charging.
- Rugged Design: Conformal-coated boards for corrosion and vibration resistance in harsh marine and mobile environments.
- Easy Installation: Hardwire or plug-in AC connections with accessible terminals for quick setup.
Specifications at a Glance:
- Inverter: 3000W continuous / 6000W surge @ 120V AC, 60Hz; 12V DC input.
- Charger: 150A multi-stage, 12V DC output.
- Transfer Switch: 30A automatic.
- Efficiency: Up to 85%; No-load draw: <1.5A.
- Operating Temperature: -20°C to 60°C (-4°F to 140°F).
- Certifications: CSA certified to UL458 (inverters), CSA C22.2 No. 107.1; FCC Class B.
- Dimensions: 15.2" L x 10.8" W x 7.9" H (387 x 275 x 201 mm); Weight: 45.0 lbs (20.4 kg).
Pair this inverter/charger with Xantrex lithium batteries or solar controllers for a complete, high-efficiency power ecosystem. Whether powering your RV adventures, marine voyages, or off-grid solar system, the Freedom SW 3000W delivers premium performance and reliability. Order now and experience Xantrex's proven engineering—stocked and ready to ship from lithiumion-batteries.com!
(For full technical details, download the datasheet or manual linked on the product page.)
