Sungold Power 12000W 48V Split Phase Pure Sine Wave Inverter Charger – 12000W Continuous / 36000W Peak Hybrid Inverter for Whole-Home Backup, Off-Grid & Large Solar Systems
Model #: 12000W 48V Split Phase Pure Sine Wave Inverter Charger SKU: SG12000W-48V-SP-INV-CHG
Product Details
Product Description for Sungold Power 12000W 48V Split Phase Pure Sine Wave Inverter Charger 12000W/36000W Peak
Sungold Power 12000W 48V Split Phase Pure Sine Wave Inverter Charger – 12000W Continuous / 36000W Peak Hybrid Inverter for Whole-Home Backup, Off-Grid & Large Solar Systems
The Sungold Power 12000W 48V Split Phase Pure Sine Wave Inverter Charger is an extreme high-power hybrid inverter designed for large-scale off-grid, grid-tie, and whole-home backup applications. With 12000W continuous output and incredible 36000W peak, it powers entire homes, workshops, farms, heavy equipment, or commercial loads while charging batteries from AC or generator sources (batteries sold separately).
Key Features • 12000W Continuous / 36000W Peak Output – Pure sine wave split-phase 120V/240V with enormous surge for running multiple heavy appliances simultaneously (central AC, well pumps, dryers, welders, full-home loads). • True Split-Phase 120V/240V – Supports dual-voltage output for complete home or large RV power. • Built-in Charger – Efficient AC-to-DC charging for 48V battery banks (lithium, AGM, gel, flooded compatible). • 48V DC Input – Works with 48V lithium (LiFePO4) or lead-acid battery systems. • Multiple Protections – Overload, over-temperature, short-circuit, low-voltage, high-voltage, and reverse polarity safeguards. • Remote Control & Display – LCD screen and optional remote panel for monitoring and control. • Quiet & Efficient – Intelligent cooling fans, low idle consumption, and high efficiency (>90%). • Rugged Design – Durable aluminum housing for indoor/outdoor use with vibration resistance.
Specifications at a Glance Output Power: 12000W continuous / 36000W peak • Input Voltage: 48VDC • Output Voltage: 120/240V AC pure sine wave split-phase • Charger: Integrated AC charger (specific amps per spec sheet) • Efficiency: >90% • Dimensions: ~24.0 × 18.0 × 10.0 in • Weight: ~120 lbs • Operating Temp: Wide range with protections • Warranty: Manufacturer warranty
Whether for whole-home backup, large off-grid systems, farms, workshops, or extreme RV/marine power, the Sungold Power 12000W 48V Inverter Charger delivers unmatched power and reliability. Order now — stocked and ready to ship from lithiumion-batteries.com!
(For full technical details, download the manual linked on the product page.)
