Renogy 48V 3500W Pure Sine Wave Solar Inverter Charger with MPPT Controller – All-in-One Hybrid Power Solution for RV, Marine, Solar, and Off-Grid Systems
Model #: RIV4835CSH1S SKU: RIV4835CSH1S-US
Product Details
Product Description for Renogy 48V 3500W Pure Sine Wave Solar Inverter Charger
Renogy 48V 3500W Pure Sine Wave Solar Inverter Charger with MPPT Controller – All-in-One Hybrid Power Solution for RV, Marine, Solar, and Off-Grid Systems
Elevate your power independence with the Renogy 48V 3500W Pure Sine Wave Solar Inverter Charger (Model: RIV4835CSH1S), a versatile, high-performance all-in-one unit combining an 80A/150V MPPT solar charge controller, 3500W inverter, and 40A AC battery charger, designed for seamless integration with lithium-ion batteries in demanding RV, marine, solar, and off-grid applications. Delivering 3500W continuous power (7000W surge) with >90% efficiency and ultra-low THD, this hybrid inverter provides clean, stable 120V AC output for sensitive electronics and high-demand appliances. Its advanced MPPT technology maximizes solar harvest, while the 4-stage charger optimizes battery life; built-in UPS ensures seamless 10ms switching during outages for uninterrupted power. Key Features:
- All-in-One Hybrid Design: Integrates 80A/150V MPPT solar controller, 3500W pure sine wave inverter, and 40A AC charger for efficient solar, grid, and generator charging in one compact unit.
- Pure Sine Wave Output: Clean, stable 120V AC power, ideal for sensitive devices like medical equipment, TVs, and laptops without humming or interference.
- Advanced MPPT Solar Charging: Captures maximum energy from solar panels with up to 99% efficiency, supporting up to 4000W PV input for optimal off-grid performance.
- 4-Stage Smart Charger: Configurable for AGM/Sealed, Gel, Flooded, Lithium, and User modes; supports LiFePO4 activation and self-heating for versatile battery compatibility.
- UPS Functionality: Automatic 10ms transfer switch between AC/solar and battery mode for blackout-proof operation in RVs and marine setups.
- Advanced Protections: Comprehensive safeguards against over-voltage, low-voltage, over-current, short-circuit, overload, and reverse polarity; integrated temperature sensor for safe charging; noise <50dB.
- High Surge Capacity: 7000W peak to handle motor startups like microwaves, fridges, or power tools without tripping.
- Efficient & Reliable: >90% inverter efficiency, 48W idle (25W in Power Saving Mode), and humidity tolerance 0-95% for energy conservation and durability.
- Rugged & Certified: IP20-rated enclosure for harsh environments; operating temperature -4°F to 104°F (-20°C to 40°C); FCC Class A Part 15, UL458 (marine supplement), CSA-C22.2 No 107.1, RoHS compliant.
Specifications at a Glance:
- Input Voltage: 48VDC / 90-140VAC (charger); PV: 120-145VDC; Output Voltage: 120V AC ±3%.
- Continuous Power: 3500W; Surge Power: 7000W; Solar Charger: 80A MPPT; AC Charger: 40A.
- Efficiency: >90% (inverter); Transfer Switch: 10ms.
- Dimensions: 20.1 x 11.2 x 7.6 in (510 x 285 x 193 mm); Weight: 63.5 lbs (28.8 kg).
- Certifications: FCC Class A Part 15, UL458, CSA-C22.2 No 107.1, RoHS.
Pair this inverter charger with our premium lithium-ion batteries and solar panels for a complete, high-efficiency power ecosystem. Whether powering RV adventures, marine voyages, or solar backups, the Renogy 48V 3500W delivers unmatched hybrid reliability, smart charging, and seamless performance. Order now and experience Renogy’s innovative power excellence—stocked and ready to ship from lithiumion-batteries.com!
(For full technical details, download the datasheet or manual linked on the product page.)
