Renogy 1000W 12V Pure Sine Wave Inverter with Power Saving Mode and Bluetooth Monitoring (New Edition)
Model #: R-INVT-PGH1-10111S-US SKU: R-INVT-PGH1-10111S-US
Product Details
Product Description for Renogy 1000W 12V Pure Sine Wave Inverter with Power Saving Mode (New Edition)
Renogy 1000W 12V Pure Sine Wave Inverter with Power Saving Mode and Bluetooth Monitoring (New Edition) – Efficient Power Conversion for RV, Marine, Solar, and Off-Grid Systems
Elevate your power independence with the Renogy 1000W 12V Pure Sine Wave Inverter with Power Saving Mode and Bluetooth Monitoring (New Edition) (Model: R-INVT-PGH1-10111S-US), a versatile, high-performance DC-to-AC converter designed for seamless integration with lithium-ion batteries in demanding RV, marine, solar, and off-grid applications. Delivering 1000W continuous power (2000W surge for 2s) with >90% efficiency and ultra-low THD <3% (linear load), this inverter provides clean, stable 120V AC output for sensitive electronics and high-demand appliances. Its innovative ECO Mode automatically enters standby when load is below 50W, reducing idle consumption to <0.3A for extended battery life, while the included Bluetooth BT-2 module enables real-time monitoring via the Renogy DC Home App for effortless energy management and diagnostics. Key Features:
- Pure Sine Wave Output: Clean, stable 120V AC power with <3% THD (linear load), ideal for sensitive devices like medical equipment, TVs, and laptops without humming or interference.
- Power Saving ECO Mode: Automatically switches to standby mode when output power is ≤50W, minimizing idle draw to <0.3A; reactivates instantly when load increases for efficient energy conservation.
- Bluetooth BT-2 Monitoring: Compatible with Renogy DC Home App (iOS/Android) for real-time data on power production, consumption, voltage, current, and customizable alerts; integrates with Renogy ONE M1/Core for intelligent system optimization.
- High Surge Capacity: 2000W peak for 2s to handle motor startups like microwaves, fridges, or power tools without tripping.
- Advanced Protections: Comprehensive safeguards against over-voltage (shutdown at 16.5V), low-voltage (alarm at 10.5V, shutdown at 10.0V), over-current, short-circuit, overload, and reverse polarity; thermally controlled fans for quiet cooling (<55dB).
- Efficient & Reliable: >90% inverter efficiency, <0.3A no-load in ECO Mode, and compatibility with lithium, AGM, or flooded batteries for optimal energy use; built-in 5V/2.1A USB port for device charging; switchable 50/60Hz output.
- Remote Control Included: Wired remote with 16.4ft cable for easy on/off and mode switching from a distance.
- Rugged & Certified: IP20-rated aluminum alloy enclosure for durability in harsh environments; operating temperature -4°F to 158°F (-20°C to 70°C); ETL Listed to UL 458 and CSA 22.2 NO 107.1-01 certified for safety and compliance.
Specifications at a Glance:
- Input Voltage: 12VDC (10-16.5V range); Output Voltage: 120V AC ±3%.
- Continuous Power: 1000W; Surge Power: 2000W (2s); Efficiency: >90%.
- Max Battery Current: 103A.
- Dimensions: 13.4 x 7.6 x 2.8 in (340 x 193 x 71 mm); Weight: 7.5 lbs (3.4 kg).
- Certifications: ETL Listed to UL 458 and CSA 22.2 NO 107.1-01, FCC Part 15 Class B.
Pair this inverter with our premium lithium-ion batteries and solar panels for a complete, high-efficiency power ecosystem. Whether powering RV adventures, marine voyages, or solar backups, the Renogy 1000W 12V with Power Saving Mode and Bluetooth delivers unmatched reliability, energy savings, smart connectivity, and clean power. Order now and experience Renogy’s innovative power excellence—stocked and ready to ship from lithiumion-batteries.com!
(For full technical details, download the datasheet or manual linked on the product page.)
