Quattro Inverter Charger - 24/5000/120-100/100 120V | Victron Energy QUA245023110
Model #: QUA245023110 SKU: VICTRON-QUA245023110
Product Details
Product Description for Victron Quattro 24/5000/120-100/100 120V
Victron Energy Quattro 24/5000/120-100/100 120V Inverter/Charger – Advanced Power Solution for Off-Grid, RV, Marine, and Solar Systems
Power up your energy independence with the Victron Quattro 24/5000/120-100/100 120V (Model: QUA245023110), a high-performance inverter/charger optimized for 24V lithium-ion battery systems. This robust unit delivers 5000VA (4000W continuous at 25°C) of pure sine wave AC power, making it perfect for off-grid solar setups, RV camping, marine vessels, and backup power applications. With dual AC inputs, PowerAssist technology, and intelligent charging, the Quattro ensures reliable, uninterrupted power while maximizing battery efficiency and system durability.
Key Features:
- Pure Sine Wave Inverter: Provides clean, stable 120V AC power with low idle consumption, ideal for sensitive electronics and high-demand appliances up to 10,000W surge.
- Dual AC Inputs & Transfer Switch: Connects to two independent AC sources (e.g., grid and generator) with a 100A transfer switch, switching in under 20ms for blackout-proof operation.
- PowerControl & PowerAssist: Prevents overloads on limited AC sources by dynamically managing charge current; boosts weak grid or generator power with battery energy for peak loads.
- 120A Adaptive Battery Charger: Optimizes charging for lithium-ion, AGM, or gel batteries with multi-stage profiles, ensuring fast recovery and extended battery life.
- Dual AC Outputs: Main output powers critical loads continuously; secondary output activates only with AC input, conserving battery for non-essential loads.
- Scalable Design: Parallel up to 6 units for 30kVA output and 720A charging; supports 120/240V split-phase or three-phase configurations for large-scale systems.
- VE.Bus Integration: Compatible with Victron’s Cerbo GX, VRM app, and remote monitoring for full control via phone, tablet, or PC—monitor, configure, and manage systems effortlessly.
- Lithium-Ion Optimized: Fully compatible with LiFePO4 and other lithium chemistries, with BMS communication for safe, efficient operation in solar or EV systems.
- Rugged & Reliable: Built for harsh environments with humidity-resistant design, fan-assisted cooling, and a 5-year limited warranty.
Specifications at a Glance:
- Inverter: 5000VA / 4000W continuous @ 25°C; 10,000W peak; 24V DC input (19-33V).
- Charger: 120A adaptive; 120V AC input (90-140V).
- Efficiency: Up to 92%; Zero-load power: 35W.
- Dimensions: 14.2 x 10.2 x 26.7 in (362 x 258 x 680 mm); Weight: 121 lbs (55 kg).
- Transfer Switch: 100A per input.
- Certifications: CE, EN/IEC standards; designed for North American 120V systems.
Pair the Quattro 24/5000 with our premium 24V lithium-ion batteries for a high-efficiency, reliable power ecosystem. Whether you’re powering off-grid cabins, marine vessels, or home energy storage, this inverter/charger delivers unmatched performance and versatility. Order now from lithiumion-batteries.com and experience Victron’s legendary Dutch engineering!
(For full technical details, download the datasheet or manual linked on the product page.)
