Chargex® 36V 75AH Lithium Battery Kit
Product: CXK3675 SKU: 36-LIB-75-K Weight: 75 lbs
Product Details
PLUG AND PLAY | This 36V 75AH kit Includes everything you need to convert your 36V Golf Cart from Lead Acid to Lithium Batteries.
3 - 12V 75AH Lithium Ion Batteries
Free - 3 Bank 10A Lithium Battery Charger
FREE SHIPPING - CONTINENTAL US ONLY
POWER & ENERGY
THE ELECTRIC ADVANTAGE
| Nominal Voltage | 12.8V (x3) 38.4V |
| Charge Voltage | 14.4V - 14.6V |
| Peak Discharge (5 Sec) | 750A |
| Continuous Charge / Discharge Rate | 75A |
| Capacity (amp hours) | 75AH |
| Capacity (watts) | 900W |
| Chemistry | Lithium Iron Phosphate (LiFePO4) |
SIZE & WEIGHT
ADVANTAGE
| Model | CXK3675 |
| Group Size | 24 |
| Weight | 25 Lbs x3 / 75 Lbs total |
| Length | 10.25" |
| Width | 6.75" |
| Height | 8.25" |
TECHNOLOGY
ADVANTAGE
| Usable Capacity (AH) | 81AH |
| Depth of Discharge | >100% DOD |
| Reserve Minutes @ 20A | 220 min |
| Reserve Minutes @ 75A | 60 min |
| Self Discharge | <3% per mo |
| Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Cell Type | Cylindrical |
| Modular | Series or Parallel Connection |
SAFETY & PROTECTION
ADVANTAGE
| Built in Automatic Battery Protection System | Internal |
| Automatic Low Voltage Disconnect | 8V |
| Automatic Short Circuit Protection | Instant |
| Automatic Over Voltage Protection | 15.8V |
| Automatic Reverse Polarity Protection | Instant |
| Internal Cell Thermal Safety Fuse | Yes |
| Flame Retardant Electrolyte | Yes |
| Length Way Circuit Boards | Yes |
| Automatic Internal Cell Balancing | Yes |
| Automatic Fault Recovery | Yes |
| Explosion Proof Stainless Steel Cells | Yes |
TEMPERATURE PERFORMANCE
ADVANTAGE
| Celsius | Fahrenheit | Usable Capacity |
| 60 | 140 | 103% |
| 50 | 122 | 102% |
| 40 | 104 | 100% |
| 30 | 86 | 100% |
| 20 | 68 | 98% |
| 10 | 50 | 92% |
| 0 | 32 | 83% |
| -10 | 14 | 80% |
| -20 | -4 | 70% |
| -30 | -22 | 60% |
| -40 | -40 | 10% |
| -50 | -58 | 0% |
FAST SHIPPING
ADVANTAGE
| Standard Shipping | UPS GROUND |
| Expedited Air Shipping | UPS WORLDWIDE EXPRESS |
| Shipping Time | 24 HOURS |
LIFETIME WARRANTY
ADVANTAGE
| Repair or Replace | First 5 Years |
| Repair or Pro Rate | Life Time |
| Detailed Warranty Information | Warranty |
This Product Is Perfect For
Motorhomes, Travel Trailers, Fifth Wheels, Boats, Yachts, Sailing, Trolling Motors, Electronics, Solar Backup Power, and Other Deep Cycle Applications.
This 36V 75AH Lithium Ion Battery Kit is the perfect replacement from an AGM, GEL or Lead Acid Battery. Designed as a "drop in replacement" meaning all you have to do is take out your old battery and place the Lithium Battery in the same way.
