DL+ 36V 60Ah Deep Cycle Trolling Motor Battery Set

Model #: DL+ 36V 60Ah SKU: DL+ 36V 60Ah Set

Quantity
Price $1,845.00 +Add to wishlist +Add to gift registry

Product Details

Dakota Lithium DL+ 36V 60Ah Deep Cycle LiFePO4 Trolling Motor Battery Set

Dakota Lithium DL+ 36V 60Ah Deep Cycle LiFePO4 Trolling Motor Battery Set (Model: DL+ 36V 60Ah) – High-Performance Power Solution for Trolling Motors, Marine, Golf Carts, Solar, and Off-Grid Systems

Empower your marine adventures with the Dakota Lithium DL+ 36V 60Ah Deep Cycle LiFePO4 Trolling Motor Battery Set (Part No: DL+ 36V 60Ah), a complete kit of three 12V 60Ah batteries wired in series for seamless 36V operation. This set delivers 60Ah of reliable LiFePO4 power at 38.4V (2.304kWh), offering 2x the usable capacity of lead-acid batteries at 65% of the weight (49.5 lbs total), with over 5,000 cycles at 80% DoD. Featuring integrated BMS for safety and efficiency, internal even-heat technology for cold-weather charging down to -20°F, and 1,000 CCA per battery for dual-purpose starting and deep cycle use, it supports high-discharge rates up to 100A continuous, making it ideal for 36V trolling motors (up to 80 lb thrust), golf carts, electric outboards, solar storage, or off-grid setups requiring maintenance-free, long-lasting performance.

Key Features:

  • Complete Set Design: Three 12V 60Ah LiFePO4 batteries pre-wired in series for drop-in 36V compatibility; replaces traditional lead-acid packs with zero modifications.
  • Integrated BMS: Protects against overcharge, over-discharge, short-circuit, and thermal issues; ensures cell balancing for maximum longevity.
  • High Discharge Capability: 100A continuous / 750A pulse (2s) / 650A pulse (5s) per battery; handles up to 300A motor controllers with 1,000 CCA for reliable starts.
  • Extended Cycle Life: 5,000+ cycles at 80% DoD, with low self-discharge for reliable standby power.
  • Versatile Compatibility: Drop-in replacement for most 36V trolling motors and marine systems; supports parallel configurations; compatible with 36V LiFePO4 chargers (8A recommended).
  • Rugged Durability: IP67-rated enclosure, vibration-resistant for marine and off-road use; operates from -20°F to 120°F with internal heating.
  • Eco-Friendly: Non-toxic LiFePO4 chemistry, recyclable, and zero maintenance compared to lead-acid alternatives.
  • 11-Year Warranty: Backed by Dakota Lithium’s commitment to quality in aerospace and defense-grade applications.

Specifications at a Glance:

  • Nominal Capacity: 60Ah at 38.4V (2.304kWh).
  • Nominal Voltage: 38.4V.
  • Charge Voltage: 43.8V; Max Charge Current: 30A.
  • Discharge: 100A continuous / 750A pulse (2s); Low Voltage Cutoff: 30V.
  • Cycle Life: 5,000+ at 80% DoD; Operating Temperature: Charge 32°F–113°F / Discharge -20°F–120°F.
  • Certifications: UN38.3, UL1642 (cells), IEC62133, CE, RoHS, ISO 9001:2015.
  • Dimensions (per battery): 9.5" L x 6.9" W x 7.44" H (242.5 x 176 x 189 mm); Weight (per battery): 16.5 lbs (7.5 kg); Total Set Weight: 49.5 lbs (22.5 kg).

Pair this battery set with Dakota Lithium 36V chargers or solar controllers for a complete, high-efficiency power ecosystem. Whether powering trolling motors, golf carts, or solar arrays, the DL+ 36V 60Ah Set delivers unmatched reliability and range. Order now and experience Dakota Lithium’s aerospace-grade engineering—stocked and ready to ship from dakotalithium.com!
