DL+ 24V 135Ah Dual Purpose Battery Set

Model #: DL+ 24V 135Ah SKU: DL+ 24V 135Ah Set

Quantity
Price $1,998.00 +Add to wishlist +Add to gift registry

Product Details

Dakota Lithium DL+ 24V 135Ah Dual Purpose LiFePO4 Battery Set

Dakota Lithium DL+ 24V 135Ah Dual Purpose LiFePO4 Battery Set (Model: DL+ 24V 135Ah) – High-Performance Power Solution for Trolling Motors, Marine, Golf Carts, Solar, and Off-Grid Systems

Elevate your marine adventures with the Dakota Lithium DL+ 24V 135Ah Dual Purpose LiFePO4 Battery Set (Part No: DL+ 24V 135Ah), a complete kit of two 12V 135Ah batteries wired in series for seamless 24V operation. This set delivers 135Ah of reliable LiFePO4 power at 25.6V (3.456kWh), offering 5x the usable capacity of lead-acid batteries at half the weight (54.4 lbs total), with over 5,000 cycles at 80% DoD. Featuring integrated BMS for safety and efficiency, internal even-heat technology for cold-weather charging down to -20°F, and 1,000 CCA per battery for dual-purpose starting and deep cycle use, it supports high-discharge rates up to 135A continuous, making it ideal for 24V trolling motors (inshore/heavy-use), golf carts, electric outboards, solar storage, or off-grid setups requiring maintenance-free, long-lasting performance.

Key Features:

  • Complete Set Design: Two 12V 135Ah LiFePO4 batteries pre-wired in series for drop-in 24V compatibility; replaces traditional lead-acid packs with zero modifications.
  • Integrated BMS: Protects against overcharge, over-discharge, short-circuit, and thermal issues; ensures cell balancing for maximum longevity.
  • High Discharge Capability: 135A continuous / 1,000A pulse (2s) / 900A pulse (5s) per battery; handles up to 270A motor controllers with 1,000 CCA for reliable starts.
  • Extended Cycle Life: 5,000+ cycles at 80% DoD, with low self-discharge for reliable standby power.
  • Versatile Compatibility: Drop-in replacement for most 24V trolling motors and marine systems; supports parallel configurations; compatible with 24V LiFePO4 chargers (5A recommended).
  • Rugged Durability: IP67-rated enclosure, vibration-resistant for marine and off-road use; operates from -4°F to 158°F with internal heating.
  • Eco-Friendly: Non-toxic LiFePO4 chemistry, recyclable, and zero maintenance compared to lead-acid alternatives.
  • 11-Year Warranty: Backed by Dakota Lithium’s commitment to quality in aerospace and defense-grade applications.

Specifications at a Glance:

  • Nominal Capacity: 135Ah at 25.6V (3.456kWh).
  • Nominal Voltage: 25.6V.
  • Charge Voltage: 29.2V; Max Charge Current: 70A.
  • Discharge: 135A continuous / 1,000A pulse (2s); Low Voltage Cutoff: 20V.
  • Cycle Life: 5,000+ at 80% DoD; Operating Temperature: Charge 32°F–113°F / Discharge -4°F–158°F.
  • Certifications: UN38.3, CE, RoHS.
  • Dimensions (per battery): 9.5" L x 6.9" W x 8.22" H (242.5 x 176 x 209 mm); Weight (per battery): 27.2 lbs (12.3 kg); Total Set Weight: 54.4 lbs (24.7 kg).

Pair this battery set with Dakota Lithium 24V chargers or solar controllers for a complete, high-efficiency power ecosystem. Whether powering trolling motors, golf carts, or solar arrays, the DL+ 24V 135Ah Set delivers unmatched reliability and range. Order now and experience Dakota Lithium’s aerospace-grade engineering—stocked and ready to ship from dakotalithium.com!
